ICSOSO is the stocking distributor for AGQ200A03Z, we have the stocks for immediate shipping and also available for long time supply. Please send us your purchase plan for AGQ200A03Z by email, we will give you a best price according your plan.
Buy AGQ200A03Z with ICSOSO
Buy with guarantee
Pricing(USD)
| 1+ | $1.43 |
|---|---|
| 10+ | $1.31 |
| 100+ | $1.19 |
| 1000+ | $1.13 |
| 10000+ | $1.10 |
AGQ200A03Z
- Part Number:
- AGQ200A03Z
- Manufacturer:
- Panasonic
- Description:
- RELAY TELECOM DPDT 2A 3V / Signal Relay 3VDC 2A DPDT( (10.6mm 8.4mm 5.4mm)) SMD
- Number of stock:
- 14238 pcs
- Lead Free Status / RoHS Status:
- Lead free / RoHS Compliant
- Data sheet:
- AGQ200A03Z.pdf
Introduction
Specifications
| Turn On Voltage (Max): | 2.25 VDC |
|---|---|
| Turn Off Voltage (Min): | 0.3 VDC |
| Termination Style: | Gull Wing |
| Switching Voltage: | 125VAC, 110VDC - Max |
| Series: | AGQ |
| Release Time: | 4ms |
| Relay Type: | Telecom |
| Packaging: | Tape & Reel (TR) |
| Other Names: | 255-2091-2 AGQ200A03Z-ND |
| Operating Temperature: | -40°C ~ 85°C |
| Operate Time: | 4ms |
| Mounting Type: | Surface Mount |
| Moisture Sensitivity Level (MSL): | 4 (72 Hours) |
| Manufacturer Standard Lead Time: | 20 Weeks |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Features: | - |
| Detailed Description: | Telecom Relay DPDT (2 Form C) Surface Mount |
| Contact Rating (Current): | 2A |
| Contact Material: | Silver Palladium (AgPd), Gold (Au) |
| Contact Form: | DPDT (2 Form C) |
| Coil Voltage: | 3VDC |
| Coil Type: | Non Latching |
| Coil Resistance: | 64.2 Ohms |
| Coil Power: | 140 mW |
| Coil Current: | 46.7mA |
